EXi: STR-1 Plucked String
244
Center-High [-Inf, –99…+99, +Inf]
This sets the slope between the Center and High Break keys.
For normal key track, use positive values.
High-Top [-Inf, –99…+99, +Inf]
This sets the slope between the High Break key and the top
of the MIDI note range. For normal key track, use positive
values.
6–2b: Amp Modulation
You can modulate the Amp level by velocity and two AMS
sources. Each of the AMS sources also has its own
secondary intensity modulation.
This modulation scales the basic Amp level and Amp EG
level parameters. If these original levels are low, the
maximum volume available with modulation will also be
reduced.
Note that there is an upper limit to Amp modulation. Once
the volume level reaches double the programmed Amp
Level and Amp EG level settings, it cannot be increased any
further.
Velocity Intensity [–99…+99]
With positive (+) values, the volume will increase as you
play harder.
With negative (–) values, the volume will decrease as you
play harder.
AMS1 [AMS Sources]
This selects the first modulation source for the Amp level.
For a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–99…+99]
This sets the initial amount of AMS1. The Intensity Mod
AMS then adds to this initial amount.
Intensity Mod AMS [AMS Sources]
This selects a secondary AMS modulation source to scale
the intensity of AMS1.
For a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–99…+99]
This controls the depth and direction of the Intensity Mod
AMS. Even if the main AMS1 Intensity is set to 0, Intensity
Mod AMS can still control the final amount of AMS A over
the full +/-99 range.
For example, if AMS1 is set to LFO1, and Intensity Mod
AMS is set to JS+Y, positive settings mean that pushing the
joystick away from yourself will increase the intensity of the
LFO modulation of Amp.
AMS2 [AMS Sources]
This selects a second modulation source for the Amp level.
For a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–99…+99]
This sets the initial amount of AMS2. The Intensity Mod
AMS then adds to this initial amount.
Intensity Mod AMS [AMS Sources]
This selects a secondary AMS modulation source to scale
the intensity of AMS2.
For a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–99…+99]
This controls the depth and direction of the Intensity Mod
AMS. Even if the main AMS2 Intensity is set to 0,
Intensity Mod AMS can still control the final amount of
AMS A over the full +/−99 range.
AMS3 [AMS Sources]
This selects a third modulation source for the Amp level. For
a list of AMS sources, see “Alternate Modulation Source
(AMS) List” on page 901.
Intensity [–99…+99]
This sets the initial amount of AMS3.
v
6–2: Page Menu Commands
• Compare →p.112
• Write Program →p.112
• Exclusive Solo →p.113
• PAGE →p.126
•MODE →p.126
