EXi: MOD-7 Waveshaping VPM Synthesizer
314
4–1b: Parameter Details
This area at the upper right of the display shows information
for both the selected jack, and the block containing that jack.
(Block name) [PCM Osc, Noise, Audio In,
VPM Osc 1…6, Mixer 1…3,
Filter A…B, Main Mix]
This read-only parameter shows the name of the selected
block.
Mode [Off, Sine, Saw, Triangle, Square,
Sine + Waveshaper, Waveshaper,
Ring Mod Only]
When a VPM Oscillator is selected, this read-only parameter
shows the Oscillator Mode.
On [Check-box]
This check-box lets you temporarily mute the output of the
block. It duplicates the similarly-named parameter on the
Oscillator’s page.
(Jack name) [Depends on block]
This read-only parameter shows the name of the selected
jack, such as Input 1.
11
PCM + VPM
PCM+4+2 -> 4-pole
12 PCM+3+3 -> 4-pole
13 PCM+2+2+2 -> 4-pole
14 PCM+2+2+1+1 -> 4-pole
15 PCM+2+1+1+1+1 -> 4-pole
16 PCM+4+2 -> parallel filters
17 PCM+3+3 -> parallel filters
18 PCM+2+2+2 -> parallel filters
19 PCM+2+2+1+1 -> parallel filters
20 PCM+all carriers -> parallel filters
21
PCM->Filter->VPM
PCM -> 4+2 -> 2-pole I
22 PCM -> 4+2 -> 2-pole II
23 PCM -> 3+3 -> 2-pole I
24 PCM -> 3+3 -> 2-pole II
25 PCM -> 2+2+2 -> 2-pole I
26 PCM -> 2+2+2 -> 2-pole II
27 PCM -> 2+2+1+1 -> 2-pole I
28 PCM -> 2+2+1+1 -> 2-pole II
29 PCM -> 3+1+1+1 -> 2-pole
30 PCM -> all carriers -> 2-pole
31
PCM->VPM -> 4-pole
PCM -> 4+2 -> 4-pole I
32 PCM -> 4+2 -> 4-pole II
33 PCM -> 3+3 -> 4-pole I
34 PCM -> 3+3 -> 4-pole II
35 PCM -> 2+2+2 -> 4-pole I
36 PCM -> 2+2+2 -> 4-pole II
37 PCM -> 2+2+1+1 -> 4-pole I
38 PCM -> 2+2+1+1 -> 4-pole II
39 PCM -> 3+1+1+1 -> 4-pole
40 PCM -> all carriers -> 4-pole
41
Noise->VPM -> 4-pole
Noise -> 4+2 -> 4-pole I
42 Noise -> 4+2 -> 4-pole II
43 Noise -> 3+3 -> 4-pole I
44 Noise -> 3+3 -> 4-pole II
45 Noise -> 2+2+2 -> 4-pole I
46 Noise -> 2+2+2 -> 4-pole II
47 Noise -> 2+2+1+1 -> 4-pole I
48 Noise -> 2+2+1+1 -> 4-pole II
49 Noise -> 3+1+1+1 -> 4-pole
50 Noise -> all carriers -> 4-pole
51
Processing
PCM -> 1 -> 4-pole
52 PCM -> 1+1+1 -> 4-pole
53 Audio -> 1 -> 4-pole
54 Audio -> 1+1+1 -> 4-pole
#Group Algorithm
55
Vintage DX
DX #1 & #2
56 DX #3
57 DX #4
58 DX #5
59 DX #6
60 DX #7, #8, & #9
61 DX #10 & #11
62 DX #12 & #13
63 DX #14 & #15
64 DX #16 & #17
65 DX #18
66 DX #19
67 DX #20
68 DX #21
69 DX #22
70 DX #23
71 DX #24
72 DX #25
73 DX #26 & #27
74 DX #28
75 DX #29
76 DX #30
77 DX #31
78 DX #32
# Group Algorithm
