Korg NAUTILUS Series Parameter Guide

Effect Guide
744
SAMPLING mode
The analog, and USB audio inputs can be processed by the
insert effects, master effects, or total effects then sampled.
You can also apply insert effects to the samples assigned to a
multisample, and resample the result.
The Bus Select settings in the Recording– Audio Input page
specify the buses to which the external inputs will be sent.
You can choose from L/R, IFX1–12, 1–4, 1/2–3/4, or Off. If
you want to apply an insert effect while sampling, choose
IFX1–12.
In the example shown in the diagram (Fig. 2–3a), the signal
from AUDIO INPUT 1 and 2 is being sent to IFX1. Use the
IFX page to select an insert effect, and edit its parameters.
The following diagram (Fig. 2–3b) shows an example of bus
settings in which the samples assigned to a multisample are
resampled with IFX1 applied. Set Bus Select (SAMPLING
8–1b) to IFX1.
When sampling ends, L/R will automatically be selected
as the Bus Select setting. Please be aware of this if you
continue sampling.
For more details on any of these sampling methods, please
see “Preparations for sampling” on page 124 of the OG.
Fig. 2–3a
Fig. 2–3b

Korg NAUTILUS Series Specifications

General

Sampling	Open Sampling System
MIDI	In, Out, Thru
Preset Combinations	384
Keyboard	61-key (NAUTILUS 61), 73-key (NAUTILUS 73), 88-key (NAUTILUS 88, RH3 weighted action)
Effects	12 Insert Effects; 2 Master Effects; 2 Total Effects
Sequencer	16-track MIDI Sequencer
Storage	Internal SSD (60 GB)
Audio Inputs	2 x 1/4"
Audio Outputs	Headphones
USB	Type A (host), Type B (device)
Weight	NAUTILUS 88: 23.1 kg
Display	8 inch TouchView™ GUI (800x600 pixels)
