Insert Effects (IFX1…IFX12) Routing
745
Analog, and USB inputs
In PROGRAM, COMBINATION, and SEQUENCER
modes, external audio sources from the analog, and USB
inputs can be processed by insert effects, master effects, and
total effects just as they can in SAMPLING mode.
You can sample while applying the NAUTILUS’s effects to
the external audio sources from these jacks, or use the
NAUTILUS as a 4-in (analog, and USB) 6-out effect
processor. You can also use an external mic input to control a
vocoder effect (026: Vocoder) applied to internal sounds.
In SEQUENCER mode you can also use the effects when
recording external audio sources to audio tracks.
In each mode, use “Audio Input” (Sampling page) to make
settings for the audio inputs. Alternatively, you can check
Use Global Settings and use the GLOBAL mode “Audio”
settings.
Set Bus Select to specify the bus to which the external audio
input will be sent. You can select L/R, IFX1–12, 1–4, 1/2–
3/4, or Off. If you want to apply an insert effect, select
IFX1–12.
Send1 (to MFX1) and Send2 (to MFX2) become effective
only when Bus Select is set to L/R or Off. If IFX1–12 is
selected, use IFX– Insert Effect page Send1 and Send2 for
the post-IFX signal.
The diagram (Fig. 2–4a) shows an example in which the
input from INPUT 1 and 2 is panned to left and right, and
sent to insert effect 1.
In MEDIA mode, effects will use the settings of the mode
in which you previously were.
