Suffix:
<Port>
.
GPIO port number.
If ALL voltages are queried, this suffix is ignored and can be
omitted.
Query parameters:
<ALL> ALL
Use ALL to measure the voltages at all GPIO pins.
Return values:
<Results> Measured voltages, either a single value or a comma-separated
list.
Default unit: V
Usage: Query only
Options: R&S ZN-B15/Z15 Var. 03
Manual operation: See "Voltage, Current" on page 521
CONTrol:GPIO<Port>:SENSe:CURRent?
[<ALL>]
Returns the results of the current measurement on the related GPIO pin or ALL GPIO
pins.
Suffix:
<Port>
.
1, ..., 10
GPIO port number
If ALL currents are queried, this suffix is ignored.
Query parameters:
<ALL> ALL
Use ALL to measure the currents at all GPIO pins.
Return values:
<Results> Measured currents, either a single value or a comma-separated
list.
Default unit: A
Usage: Query only
Options: R&S ZN-B15/Z15 Var. 03
Manual operation: See "Voltage, Current" on page 521
CONTrol:GPIO:SENSe:SUMCurrent? <GpioPorts>
Returns the sum of the currents measured at the specified GPIO ports
Query parameters:
<GpioPorts> Comma-separated list of GPIO port numbers
The list must contain minimum two and maximum 10 numbers
between 1 and 10 in arbitrary order.
