Command Reference
R&S
®
ZNB/ZNBT
1002User Manual 1173.9163.02 ─ 55
Usage: Event
Manual operation: See "Apply" on page 520
CONTrol<Ch>:GPIO<Port>[:STATe] <EnableInSequence>
Enables/disables GPIO port <port> in the Sweep Sequencer for channel <Ch> (see
CONTrol<Ch>:SEQuence<Nr>:GPIO<Port>:VOLTage and CONTrol<Ch>:
SEGMent<Nr>:SEQuence<Nr>:GPIO<Port>:VOLTage).
Suffix:
<Ch>
.
Channel number
<Port> GPIO port number
Parameters:
<EnableInSequence> Enabled state
Manual operation: See "Seq." on page 519
CONTrol<Ch>:GPIO<Port>:RANGe
<Current Range>
Defines an upper bound of the current to be measured on the respective GPIO pin.
The analyzer firmware automatically selects a suitable shunt resistance, which can be
queried using CONTrol<Ch>:GPIO<Port>:SHUNt?.
Suffix:
<Ch>
.
Channel number
<Port> GPIO port number 1, ..., 10
Parameters:
<Current Range>
Ports 1 to 8: { 2·10
n
μA | n=1,...,5 }
Ports 9 and 10: {0 mA, 100 mA}
Note: The high resistance configuration of pins 9 and 10
requires FPGA version 6.1.0 or higher. For older versions of the
R&S ZN-B15/Z15 Var. 03, pins 9 and 10 have the same current
range as pins 1 to 8.
Default unit: A
Example:
:CONTrol:GPIO1:RANGe 2uA
:CONTrol:GPIO2:RANGe 20uA
:CONTrol:GPIO3:RANGe 200uA
:CONTrol:GPIO4:RANGe 2mA
:CONTrol:GPIO5:RANGe 20mA
:CONTrol:GPIO9:RANGe 0
:CONTrol:GPIO9:RANGe 100mA
Options: R&S ZN-B15/Z15 Var. 03
Manual operation: See "Range / Shunt" on page 521
SCPI Command Reference
