Usage: Query only
Manual operation: See "Range" on page 522
CONTrol<Ch>:SEGMent<Nr>:SEQuence:CLEar:ALL
For segmented sweeps this command deletes the command/switch sequence for the
respective channel and sweep segment (defined using CONTrol<Ch>:
SEGMent<Nr>:SEQuence<Nr>:RFFE<Bus>:COMMand:DATA and CONTrol<Ch>:
SEGMent<Nr>:SEQuence<Nr>:GPIO<Port>:VOLTage).
Suffix:
<Ch>
.
Channel number
<Nr> Segment number
Usage: Event
Manual operation: See "Range" on page 522
CONTrol<Ch>:SEGMent<Nr>:SEQuence<Nr>:DELay <Delay>
For segmented sweeps this command allows to introduce delays between subsequent
sequence steps and between the final sequence step and the sweep (segment) start.
The command/switch sequences are defined using CONTrol<Ch>:SEGMent<Nr>:
SEQuence<Nr>:RFFE<Bus>:COMMand:DATA and CONTrol<Ch>:SEGMent<Nr>:
SEQuence<Nr>:GPIO<Port>:VOLTage.
Suffix:
<Ch>
.
Channel number
<Nr> Segment number
<Nr> Sequence number, defining the order in which the commands
shall be executed.
For every channel, segment and RFFE interface, the sequence
numbers must be consecutive, starting at 1; reusing a sequence
number overwrites a previously defined command.
Parameters:
<Delay> Delay time
Default unit: s
Manual operation: See "Wait (Sweep Sequencer Table)" on page 523
CONTrol<Ch>:SEGMent<Nr>:SEQuence<Nr>:GPIO<Port>:VOLTage <Voltage>
For segmented sweeps this command allows to define the GPIO voltage settings to be
applied at the start of each segment.
The GPIO ports can be enabled/disabled using CONTrol<Ch>:GPIO<Port>[:
STATe]. Complementary RFFE commands can be defined using CONTrol<Ch>:
SEGMent<Nr>:SEQuence<Nr>:RFFE<Bus>:COMMand:DATA.
