Parameters:
<UppEdge> Lower or upper edge of the zoom window. Range and unit
depend on the measured quantity, see "Units for DISPlay... com-
mands" on page 1023.
Default unit: NN
<TraceName> Optional string parameter for the trace name, e.g. 'Trc4'. If this
optional parameter is present, both numeric suffixes are ignored
(trace names must be unique across different channels and win-
dows).
Example: See DISPlay[:WINDow<Wnd>]:TRACe<WndTr>:ZOOM[:
STATe]
Manual operation: See "Max / Min / Start / Stop" on page 301
DISPlay:ANNotation:CHANnel[:STATe]
<Boolean>
DISPlay:ANNotation:TRACe[:STATe] <Boolean>
Shows or hides the channel/trace list(s) in all diagrams of the current recall set.
Parameters:
<Boolean> ON | OFF - show or hide information element(s).
*RST: ON
Example:
*RST; :DISP:ANN:TRAC OFF; CHAN ON; FREQ OFF
Create diagram area no. 1 (with default trace) and hide the trace
list. Keep the channel list but hide the swept frequency range.
Manual operation: See "Trace Info" on page 689
DISPlay:ANNotation:FREQuency[:STATe] <Boolean>
Unmasks or masks all stimulus values in the VNA GUI for the active recall set.
Parameters:
<Boolean> ON | OFF - unmask or mask stimulus values
*RST: ON - all stimulus values unmasked
Example:
*RST; :DISP:ANN:FREQ OFF
Create diagram area no. 1 (with default trace) and mask all stim-
ulus values.
Manual operation: See "Hide Sensitive Information" on page 689
DISPlay:CMAP:LIMit:FCOLorize[:STATe] <Boolean>
Assigns a different trace color to failed trace segments ("Colorize Trace when Failed").
Parameters:
<Boolean> ON | OFF - colorize trace or keep original trace color.
*RST: n/a (a *RST does not affect the setting). In the fac-
tory configuration, OFF is preset.
