<RippleLimFile> String parameter to specify the name and directory of the cre-
ated ripple limit file. The default extension (manual control) for
ripple limit files is *.ripple, although other extensions are
allowed.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
Example: See MMEMory:LOAD:LIMit
Usage: Setting only
Manual operation: See "Recall Ripple Test.../Save Ripple Test..." on page 354
MMEMory:STORe:SEGMent
<Channel>, <SweepSegFile>
Saves the sweep segment definition of the related channel to a an ASCII file. Sweep
segments are defined using [SENSe:]SEGMent<Seg>... commands.
Setting parameters:
<Channel> Channel number
<SweepSegFile> String parameter to specify the name and directory of the cre-
ated sweep segment file. The default extension (manual control)
for sweep segment files is *.SegList, although other exten-
sions are allowed.
If no path is specified the analyzer searches the current direc-
tory, to be queried with MMEMory:CDIRectory
Example: See MMEMory:LOAD:SEGMent
Usage: Setting only
Manual operation: See "Import.../ Export..." on page 402
MMEMory:STORe:STATe <Compatibility>, <RecallSetFile>
Stores the configuration data of the current recall set to the specified recall set file.
MMEMory:STORe:STATe also renames the current recall set. See example for
MMEMory:LOAD:STATe.
Setting parameters:
<Compatibility> 1 (this value is used for compatibility with the SCPI standard but
ignored).
<RecallSetFile> String parameter to specify the absolute or relative path of the
created recall set file. Relative paths are evaluated relative to
the current directory (see MMEMory:CDIRectory).
The default extension for recall set files is znx. Unless you
specify znxml as file name extension, recall sets are always
stored in znx file format.
Example: See MMEMory:LOAD:STATe
Usage: Setting only
