OUTPut:UPORt:ECBits.................................................................................................1104
OUTPut<Ch>[:STATe]................................................................................................... 1104
OUTPut<Ch>:UPORt:SEGMent<Seg>:STATe................................................................. 1104
OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue]............................................................... 1105
OUTPut<Ch>:UPORt[:VALue]........................................................................................1106
OUTPut:UPORt:ECBits <Boolean>
Defines the usage of pins 16 to 19 of the USER PORT connector.
Parameters:
<Boolean> ON – channel bits 4 to 7
OFF – drive port 1 to 4
*RST: ON
Example: See OUTPut<Ch>:UPORt[:VALue]
Manual operation: See "Pin 16 - 19" on page 706
OUTPut<Ch>[:STATe]
<Boolean>
Turns the internal source power at all ports and the power of all external generators on
or off.
Suffix:
<Ch>
.
Channel number. This suffix is ignored; the setting is valid for all
channels.
Parameters:
<Boolean> ON | OFF - switch the power on or off.
*RST: ON
Example:
OUTP OFF
Turn off the RF source power.
Manual operation: See "RF Off All Channels" on page 385
OUTPut<Ch>:UPORt:SEGMent<Seg>:STATe <Boolean>
Enables or disables segment bits for the sweep segments in channel no. <Ch>; see
OUTPut<Ch>:UPORt:SEGMent<Seg>[:VALue]. The command is valid for segmen-
ted frequency sweep.
Suffix:
<Ch>
.
Channel number.
<Seg> Sweep segment number. This suffix is ignored; the setting is
valid for all segments.
Parameters:
<Boolean> ON | OFF - Enables or disables channel bits.
*RST: OFF
