Example: See SOURce<Ch>:FREQuency<PhyPt>:CONVersion:
ARBitrary:IFRequency
Manual operation: See "Load Match Correction" on page 495
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:FIXed<Stg> <InputOutput>
Selects the mixer input or output signal which is at the fixed frequency defined via
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:MFFixed.
Suffix:
<Ch>
.
Channel number.
<Stg> Counter for fixed signal (1 if only one mixer stage is used, 1 or 2
for 2 mixer stages).
Parameters:
<InputOutput> RF | LO | LO1 | LO2 | IF
RF - mixer input signal
LO | LO1 | LO2 - local oscillator signal 1 or 2 (for 2-stage mixer
measurements, see [SENSe<Ch>:]FREQuency:
CONVersion:MIXer:STAGes)
IF - mixer output signal (mixing product)
*RST: LO
Example: See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:
MFFixed
[SENSe<Ch>:]FREQuency:CONVersion:MIXer:FUNDamental <InputOutput>
Selects the mixer input or output signal which is at the fundamental frequency (channel
frequency, to be defined by means of [SENSe<Ch>:]FREQuency:STARt,
[SENSe<Ch>:]FREQuency:STOP, [SENSe<Ch>:]FREQuency:CW etc.).
Suffix:
<Ch>
.
Channel number.
Parameters:
<InputOutput> RF | LO | LO1 | LO2 | IF
RF - mixer input signal
LO | LO1 | LO2 - local oscillator signal 1 or 2 (for 2-stage mixer
measurements; see [SENSe<Ch>:]FREQuency:
CONVersion:MIXer:STAGes)
IF - mixer output signal (mixing product)
*RST: RF
Example: See [SENSe<Ch>:]FREQuency:CONVersion:MIXer:
MFFixed
Manual operation: See "Frequency tab" on page 562
