Command Reference
R&S
®
ZNB/ZNBT
1294User Manual 1173.9163.02 ─ 55
SOURce<Ch>:POWer<PhyPt>:GENerator<Gen>:PERManent[:STATe] <Boolean>
Defines whether the external generator is available as an external signal source in the
test setup. External generators are always on for all partial measurements.
Suffix:
<Ch>
.
Channel number
<PhyPt> Test port number of the analyzer. This suffix is ignored; the gen-
erator is selected via <Gen>.
<Gen> Generator number
Parameters:
<Boolean> ON - generator no. <PhyPt> is available.
OFF - generator is available only if a measurement result with a
generator drive port is selected
*RST: OFF
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02',
'gpib0', '21'
Configure an R&S SME02 generator as external generator no.
1, assigning the name Ext. Gen. 1 and a GPIB address 21.
SOUR:POW:GEN:PERM ON
Activate the generator as an external signal source.
Manual operation: See "Gen" on page 526
SOURce<Ch>:POWer<PhyPt>:GENerator<Gen>:STATe <Boolean>
Turns an external generator numbered <Gen> on or off.
Suffix:
<Ch>
.
Channel number
<PhyPt> Test port number of the analyzer. This suffix is ignored; the gen-
erator is selected via <Gen>.
<Gen> Generator number
Parameters:
<Boolean> ON | OFF - generator is on or off
*RST: ON
Example:
SYST:COMM:RDEV:GEN1:DEF 'Ext. Gen. 1', 'SME02',
'gpib0', '21'
Configure an R&S SME02 generator as external generator no.
1, assigning the name "Ext. Gen. 1" and a GPIB address 21.
SOUR:POW:GEN:STAT OFF
Turn the external generator off. In the "Port Configuration" dia-
log, "RF Off" is checked for generator no. 1.
Manual operation: See "RF Off" on page 526
