Options: R&S ZNB/ZNBT-K20
Manual operation: See "CTLE Equalizer" on page 650
CALCulate<Chn>:EYE:EQUalization:STATe <Boolean>
Enables/disables the CTLE at the receiver simulation of the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
The parameters of the equalizer (a two-pole filter with single zero) can be specified
using CALCulate<Chn>:EYE:EQUalization:CTLE:DC, CALCulate<Chn>:EYE:
EQUalization:CTLE:ZERO and CALCulate<Chn>:EYE:EQUalization:CTLE:
POLE<1|2>.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> *RST: OFF
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Active" on page 649
CALCulate<Chn>:EYE:INPut:BPATtern:TYPE <BitPattern>
Defines the type of bit stream to be simulated for the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<BitPattern> PRBS | USER
PRBS
Pseudo-random binary sequence of selectable length (see
CALCulate<Chn>:EYE:INPut:LENGth:PRBS)
USER
User defined bit pattern, can be loaded from a 7-bit ASCII file
(see MMEMory:LOAD:EYE:BPATtern) and is repeated until the
configured bit length is reached (see CALCulate<Chn>:EYE:
INPut:LENGth:BITS). If not loaded from file, the default pat-
tern "10" is repeated.
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Bit Stream" on page 639
