R&S ZNB - Page 800

Command Reference
R&S
®
ZNB/ZNBT
800User Manual 1173.9163.02 ─ 55
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<PrbsLength> L5 | L7 | L9 | L10 | L11 | L13 | L15
Li represents an actual sequence length of 2
i
- 1.
Options: R&S ZNB/ZNBT-K20
Manual operation: See "Length" on page 639
CALCulate<Chn>:EYE:INPut:MODulation <PAMType>
Defines or queries the modulation type of the signal to be simulated for the related eye
diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<PAMType> NRZ | PM4 | PM8 | PM16
NRZ, PAM-4, PAM-8 or PAM-16
*RST: NRZ
Manual operation: See "Modulation" on page 640
CALCulate<Chn>:EYE:INPut:OLEVel <OneLevel>
CALCulate<Chn>:EYE:INPut:ZLEVel <VoltageLevel>
Defines the highest/lowest (nominal) voltage level of the simulated digital signal gener-
ating the related eye diagram.
This command will raise an execution error if the active trace in the selected channel is
not an eye diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<VoltageLevel> Default unit: V
Options: R&S ZNB/ZNBT-K20
Manual operation: See "High Level / Low Level" on page 640
CALCulate<Chn>:EYE:INPut:RTIMe:DATA <RiseTime>
Sets/gets the rise time of the low pass in the binary signal generator simulation of the
related eye diagram.
SCPI Command Reference
