Parameters:
<Active> Boolean
Manual operation: See "Threshold Settings" on page 371
CALCulate<Chn>:MARKer:SEARch:BFILter:RESult[:STATe] <Boolean>
Shows or hides the bandfilter search results in the diagram area.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Boolean> ON - show the bandfilter search results. If no bandfilter search
has been initiated before (CALCulate<Chn>:MARKer<Mk>:
FUNCtion:EXECute BFILter), nothing is displayed.
OFF - hide the bandfilter search results.
*RST: OFF
Example: See CALCulate<Chn>:MARKer<Mk>:BWIDth
Manual operation: See "Result Off" on page 377
CALCulate<Chn>:MARKer:SEARch:BFILter:RESult[:STATe]:AREA
<HorizontalPos>, <VerticalPos>
Moves the bandfilter search info field for the active trace <Chn> to one of nine prede-
fined positions in the active diagram.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<HorizontalPos> LEFT | MID | RIGHt
Horizontal position
<VerticalPos> TOP | MID | BOTTom
Vertical position
Example: See CALCulate<Chn>:MARKer<Mk>:BWIDth
Manual operation: See "Bandpass Ref to Max" on page 375
CALCulate<Chn>:MARKer<Mk>:AOFF
Removes all markers from all traces of the active recall set. The removed markers
remember their properties (stimulus value, format, delta mode, number) when they are
restored (CALCulate<Chn>:MARKer<Mk>[:STATe] ON). The marker properties are
definitely lost if the associated trace is deleted.
Suffix:
<Chn>
.
Channel number used to identify the active trace. If unspecified
the numeric suffix is set to 1.
