R&S ZNB User Manual

Command Reference
R&S
®
ZNB/ZNBT
900User Manual 1173.9163.02 ─ 55
Setting parameters:
<TraceName> Trace name, e.g. 'Trc4'. See "Rules for trace names" in Chap-
ter 6.5.1.3, "Trace Manager Dialog", on page 304.
Example:
CALCulate4:PARameter:SDEFine 'Ch4Tr1', 'S11'
Create channel 4 and a trace named Ch4Tr1 to measure the
input reflection coefficient S
11
.
CALCulate4:PAR:CAT?
Query the traces assigned to channel 4. Ch4Tr1 is the only
trace assigned to channel 4, so the response is
'CH4TR1,S11'.
CALCulate4:PARameter:SDEFine 'CH4TR2', 'S21';
SDEFine 'CH4TR3', 'S12'; SDEFine 'CH4TR4',
'S22'
Create three more traces for the remaining 2-port S-parameters.
CALCulate4:PARameter:DELete 'CH4TR1'
Delete the first created trace.
CALCulate4:PARameter:DELete:CALL
Delete the remaining three traces in channel 4.
CALCulate:PARameter:DELete:ALL
Delete all traces, including the default trace Trc1 in channel 1.
Usage:
Setting only
Manual operation: See "Delete Trace" on page 303
CALCulate<Ch>:PARameter:DELete:CALL
Deletes all traces in channel no. <Ch>.
Suffix:
<Ch>
.
Channel number
Example: See CALCulate<Ch>:PARameter:DELete
Usage: Event
Manual operation: See "Delete Trace" on page 303
CALCulate<Ch>:PARameter:DELete:CMEMory
Deletes all memory traces in channel <Ch>.
Suffix:
<Ch>
.
Channel number
Usage: Event
CALCulate<Ch>:PARameter:DELete:SGRoup
Deletes a group of logical ports (S-parameter group), previously defined via
CALCulate<Ch>:PARameter:DEFine:SGRoup.
SCPI Command Reference
