'IM3UOR' | 'IM3LOR' | 'IM3MOR' | 'IM5UOR' ...
'IM9MOR'
Intermodulation product (as explained above) displayed in dB units relative
to the measured lower tone level at DUT output ("intermodulation suppres-
sion")
'IP3UO' | 'IP3LO' | 'IP3MO' | 'IP5UO' ... 'IP9MO' Intercept point IP<order><side>O where <order> = 3 | 5 | 7 | 9, <side> = U |
L | M (for upper or lower or major), at DUT output
UTI | UTO | LTI | LTO Upper or lower tone at DUT input or output
*) Selecting a parameter Y...<n><m> or Z...<n><m> sets the range of port numbers to
be considered for the Y and Z-parameter measurement to <n>:<m>.
CALCulate<Ch>:PARameter:SDEFine:SENDed <TraceName>, <Result>
Creates a trace and assigns a channel number, a name and a measurement parame-
ter to it. The trace becomes the active trace in the channel but is not displayed.
Similar to CALCulate<Ch>:PARameter:SDEFine, but in presence of balanced ports
this command distinguishes between
●
single-ended S-parameters for logical ports (SSS<Li><Lj>)
●
"raw" single-ended S-parameters referring to physical ports (S<Pi><Pj>)
Suffix:
<Ch>
.
Channel number
Setting parameters:
<TraceName> Trace name
<Result> Measured quantity
Usage: Setting only
Manual operation: See "S-Parameter (selector)" on page 256
CALCulate<Ch>:PARameter:SELect <TraceName>
Selects an existing trace as the active trace of the channel. All trace commands with-
out explicit reference to the trace name act on the active trace (e.g.
CALCulate<Chn>:FORMat). CALCulate<Ch>:PARameter:SELect is also neces-
sary if the active trace of a channel has been deleted.
Suffix:
<Ch>
.
Channel number.
Parameters:
<TraceName> Trace name, e.g. 'Trc4'. See "Rules for trace names" in "Table
Area" on page 305.
