Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Result> S | Y | Z
S-parameters, Y-parameters, Z-parameters
Example:
*RST; CALC:PAR:MEAS 'Trc1'", '"Y-S22'
Select the converted admittance Y <-- S22 as measurement
parameter of the default trace.
CALC:TRAN:COMP S
Convert the converted Y-parameter into an S-parameter.
CALCulate<Chn>:TRANsform:IMPedance:RNORmal <Model>
Selects the theory for the renormalization of port impedances. The selection has an
impact on the conversion formulas for wave quantities and S-parameters.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<Model> TWAVes | PWAVes
TWAVes - travelling waves
PWAVes - power waves
*RST: TWAVes
Example: See [SENSe<Ch>:]PORT<PhyPt>:ZREFerence
Manual operation: See "Renormalization According to Theory of" on page 265
CALCulate<Chn>:TRANsform:TIME[:TYPE] <TransformType>
Selects the time domain transformation type.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<TransformType> BPASs | LPASs
BPASs - band pass impulse (only impulse response; a step
response CALCulate<Chn>:TRANsform:TIME:STIMulus
STEP is automatically changed to impulse response)
LPASs - low pass (impulse or step response, depending on
CALCulate<Chn>:TRANsform:TIME:STIMulus setting)
*RST: BPASs
