Table 8-8: Circuit models for ground loop port embedding/deembedding
Parameter Circuit model Pictogram
FIMPort File import, no circuit model
SL Shunt L
SC Shunt C
SG Shunt C
Table 8-9: Circuit models for differential match embedding
Parameter Circuit model Pictogram
FIMPort File import, generic 2-port (no circuit model)
SHLC Shunt L, shunt C
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>[:STATe]........... 947
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:
PARameters:C<Cmp>.......................................................................................... 948
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:
PARameters:DATA<Port>..................................................................................... 949
CALCulate<Ch>:TRANsform:VNETworks:BALanced:DEEMbedding<LogPt>:
PARameters:G<Cmp>..........................................................................................950
