Command Reference
R&S
®
ZNB/ZNBT
958User Manual 1173.9163.02 ─ 55
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number (balanced port)
Parameters:
<Boolean> ON | OFF - embedding active or inactive
*RST: OFF
Manual operation: See "Active" on page 577
CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:EMBedding<LogPt>:
PARameters:C<Cmp> <CircuitModel>[, <Capacitance>]
Specifies the capacitance value C in the "Shunt L, Shunt C" lumped element model for
differential match embedding.
In the query form, the <Capacitance> parameter must be omitted.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number (balanced port)
<Cmp> Must be omitted or set to 1.
Parameters:
<CircuitModel> SHLC
Currently only the "Shunt L, Shunt C" lumped element model is
supported
<Capacitance> Range: -1mF to 1 mF.
Increment: 1 fF (1E-15 F)
*RST: 1 pF (1E-12 F)
Default unit: F
Manual operation: See "Network" on page 611
CALCulate<Ch>:TRANsform:VNETworks:DIFFerential:EMBedding<LogPt>:
PARameters:DATA <Interchange>, <SParamTrcs>
Defines a Differential Match Embedding network for a balanced port based on the
given S-Parameter traces.
Use MMEMory:LOAD:VNETworks<Ch>:DIFFerential:EMBedding<LogPt> to
load circuit data from a Touchstone file located at the R&S ZNB/ZNBT's file system
instead.
Suffix:
<Ch>
.
Channel number
<LogPt> Logical port number of a balanced port
Setting parameters:
<Interchange> FPORts | IPORts | SGATes
SCPI Command Reference
