ossiblecausesPossiblesolutions
Externalsonar
module:Sea
Talkhs
/RayNetnetwork
problem.
•Checkthattheunitiscorrectlyconnectedtothe
Displayornetworkswitch.Checkallconnections
ensuringconnectionsaresecure,cleanandfree
fromcorrosion,replaceifnecessary.
Externalsonar
module:Software
mismatchbetween
equipment
mayprevent
communication.
EnsureallR
aymarineproductscontainthelatest
availablesoftware,checktheRaymarinewebsite:
www.raymarine.com/softwareforsoftware
compatibility.
Nodepthreading/lostbottomlock
P ossiblecausesPossiblesolutions
T ransducerlocation
Checkthatthetransducerhasbeeninstalledin
accordancewiththeinstructionsprovidedwiththe
transducer.
T ransducerangle
Ifthetransducerangleistoogreatthebeamcan
missthebottom,adjusttransducerangleand
recheck.
T ransducerkicked-up
Ifthetransducerhasakick-upmechanism,check
thatithasnotkickedupduetohittinganobject.
P owersource
insufficient
Withtheproductunderload,usingamulti-meter,
checkthepowersupplyvoltageasclosetotheunit
aspossibletoestablishactualvoltagewhenthe
currentisflowing.(Checkyourproduct’sTechnical
specificationforpowersupplyrequirements.)
Damagedorfouled
transducer
Checktransducercondition,ensuringitisnot
damagedandisfreefromdebris/fouling.If
necessary ,cleanorreplaceyourtransducer.
Aftercleaningorreplacementcoatthetransducer
usingawater-basedanti-foulingpaint.
P
ossiblecausesPossiblesolutions
Damagedcables
1.Checktheunit’
sconnectorforbrokenorbent
pins.
2.Checkthatthecableconnectorisfullyinserted
intotheunitandthatthelockingcollarisinthe
lockedposition.
3.Checkthecableandconnectorsforsignsof
damageorcorrosion,replaceifnecessary.
4.Withtheunitturnedon,tryflexingthepower
cableneartothedisplayconnectortosee
ifthiscausestheunittore-boot/losepower,
replaceifnecessary.
5.Checkthevessel’sbatteryvoltage,the
conditionofthebatteryterminalsandpower
supplycables,ensuringconnectionsare
secure,cleanandfreefromcorrosion,replace
ifnecessary.
6.Withtheproductunderload,usinga
multi-meter,checkforhighvoltagedropacross
allconnectors/fusesetc(thiscancausethe
Fishfinderapplicationstostopscrollingorthe
unittoreset/turnoff),replaceifnecessary.
Vesselspeedtoo
high
Slowvesselspeedandrecheck.
Bottomtooshallowor
toodeep
Thebottomdepthmaybeoutsideofthe
transducersdepthrange
,movevesseltoshallower
ordeeperwatersasrelevantandrecheck.
Pingdepthlimitset
Ifusingatransducerwithgreaterthan600W
power
,checkifthe[Pingdepthlimit]hasbeen
enabled:[Menu>Settings>Transducer>Ping
depthlimit].
Ifyouareinwaterdeeperthanthespecified[Ping
depthlimit]thenthetransducermaynotprovide
depthreadings.
Disableoradjustsettingandretry.
T roubleshooting
461
