6.2 PUNCHING PATTERNS
The StreamPunch uses a variety of easily interchangeable die sets that allow you to punch
documents in line for several different binding styles. By selecting the appropriate die set, you can
use your StreamPunch to punch documents in any of the binding styles indicated.
North America Europe / Australia
3 hole 4 hole
VeloBind 11 hole VeloBind 12 hole
WireBind (2 Types)
- 21 hole WireBind
- 32 hole WireBind
WireBind (2 Types)
- 23 hole WireBind
- 34 hole WireBind
ColorCoil 44 hole ColorCoil 47 hole
ProClick 32 Hole ProClick 34 Hole
Plastic Comb 19 Hole Plastic Comb 20 Hole & 21 Hole
Please note that each punching style listed above requires a separate die set for the StreamPunch.
The StreamPunch can hold up to four Die Sets within it’s cabinet (one in the operating slot and
three in the storage area.
To purchase additional or separate Die Sets, contact your authorized reseller.
6.3 CHANGING THE PUNCH DIE SETS
Your StreamPunch offers the convenience of interchangeable die sets, allowing you to
economically punch documents for a wide variety of binding styles. Changing the machines die sets
is both quick and easy, as the following instructions illustrate:
Removing Die Sets from the Machine: The interchangeable die set slot of the StreamPunch is
located on the right front side of the machine. If a die set “M” is already installed in your
StreamPunch, you can easily remove the die set by following these instructions:
Step 1: Stop the printer/copier.
Step 2: Open the StreamPunch access door panel.
Step 3: Set StreamPunch to the OFF (O) mode.
Step 4: Securely grasp the handle and tug firmly. This firm tug disengages the Automatic
Latching Mechanism, and allows the die set to slide out.
Step 5: Continue pulling on the handle until the Die Set is fully removed.
Step 6: Properly store the removed Die Set in the Die Set storage area of the StreamPunch
(keep away from dust, dirt, accidental falls from the edge of counters etc.).
Step 7: Select the desired Die Set for your new job and slide it into the Die Set slot. Push Die
Set in firmly until it latches.
Step 8: Set the StreamPunch to the ON (I) mode.
Step 9: Close the Access Door Panel.
Step10: Enable punch and proceed with your printing and punching job.
CAUTION: POSSIBLE PINCH POINT HAZARD. WHEN INSTALLING DIE SETS INTO YOUR
StreamPunch, ALWAYS KEEP FINGERS AND BODY PARTS OUT OF THE MACHINE’S DIE SET
SLOT AND AWAY FROM ALL AREAS OF THE DIE SET EXCEPT FOR THE FINGER HOLE IN
THE DIE SET. FAILURE TO OBSERVE THESE PRECAUTIONS MAY RESULT IN INJURY.
