GENERAL SPECIFICATIONS
B234/B235/B236/D101/D102/D103 7-18 SM
7.1.12 PERFECT BINDER (D391)
Compatible Host
Machines
D101/D102/D103
Paper Positioning Center aligned
Delivery Face-down
Signature Thickness 10 to 200 sheets (64 to 80 g/m
2
)
10 to 150 sheets (81 to 105 g/m
2
)
Max. thickness: Up to 23 mm (0.9 in.)
Paper Size Signature Width: 182 to 228.6 mm
Length: 257 to 320 mm
Cover Width: 257 to 330.2 mm
Length: 364 to 487.7 mm
Paper Thickness Signature 64 to 163 g/m
2
Cover 90 to 300 g/m
2
Finished Size Width 139.7 mm to 216 mm
Length 201 to 297 mm
Trimming Range Top 6 to 28 mm
Bottom 6 to 28 mm
Fore Edge 6 to 40 mm
Recommended Cover/Signature Size Ratios
Target Signature Cover
A4 SR A4
(225 x 320 mm)
13"x19.2"
13"x19"
13"x18"
SRA3 (320x450 mm)
B5 A4 A3
A5 B5 B4
LT 9"x12" 13"x19.2"
13"x19"
Trimming Modes 3 cuts: Bottom, top, fore edge
1 cut: Fore edge (Limit: 297 mm)
No cuts
Downstream Delivery Straight-through, no binding
Size Width: 98.4 to 330.2 mm
Length: 139.7 to 500 mm
Paper Weight 52 to 300 g/m
2
Book Output Tray Max.: 25 mm (80g/m
2
)
Book door locked during operation
Warm-up Time Less than 380 sec. (6.3 min.)
Glue Capacity Glue vat 380 g (continuous pellet supply)
Approximately A4 to B5 100 books
Trimmings Box Capacity More than 15 books
Approx. A4 to B5 of 100 sheets each, 80 g/m
2
Dimensions (w x d x h) 1090 x 791 x 1387 mm (43 x 31 x 53.5 in.)
Weight 335 kg (737 lb.)
Power Supply EU: 220 to 240V 50/60 Hz
NA: 208 60 Hz
Power Consumption Less than 623 W (with inserter)
