Main Service Program Mode Tables
SM 5-161 B234/B235/B236/D101/D102/D103
Service
Tables
3750
Reset to Defaults
Super User Only
User SP
Do this SP and touch [Execute] to reset all the settings for the TCRU units and their
components.
• The TCRU units are the units designated for removal and replacement at the work
site by trained users.
• The reset done with this SP does not affect the PM counters. The PM counters
must be reset with SP3730
001 Reset to Defaults Resets all the settings for the TCRU units to their factory
defaults.
SP6xxx Peripherals
6700
Staple Position Adjustment
User SP
Use this SP to shift the position of the stapling done by the corner stapler of the 3K
finisher (B830). This SP shifts the staple position forward and back across the
direction of paper feed.
• Use the “•” key to toggle between + and –.
• A larger value shifts the stapling position to shift forward.
• A smaller value shifts the stapling position backward.
001 A3 SEF
002 B4 SEF
003 A4 SEF
004 A4 LEF
005 B5 SEF
006 B5 LEF
007 DLT SEF
008 LG SEF
009 LT SEF
010 LT LEF
011 Custom Size
The settings are done for each paper size.
SEF denotes "Short Edge Feed".
LEF denotes "Long Edge Feed".
[-2 to +2 / 0 / 0.5 mm]
6705
Adj Punch Hole: With Feed
User SP
Use this SP to shift the position of the punching done by the Punch Unit B831
installed in the 3K finisher. This SP shifts the punching position left and right in the
direction of paper feed. There are three versions of the Punch Unit B831 1) NA 2/3
(2 or 3 hole punching selectable for the job), 2) NA 4 (4 hole punching only), and 3)
EU 2/4 (2 or 4 hole punching selectable for the job)
[-7.5~+7.5 / 0 / 0.5 mm]
• Use the “•/*” key to toggle between + and –.
• A larger value shifts the punch holes away from the edge of the paper.
• A smaller value shifts the punch holes toward the edge of the paper.
001 2-Hole: JPN
Japan Only
002 3-Hole: NA North America, 3-hole punching
003 4-Hole: Europe Europe, 4-hole punching
004 4-Hole: NA North America, 4-hole punch
005 2-Hole: NA North America, 2-hole punching
006 1-Hole: JPN
Japan Only
