BEFORE YOU BEGIN…
B234/B235/B236/D101/D102/D103 1-10 SM
1.2.3 SPECIAL POINTS ABOUT INSTALLATION
This table summarizes the recommended order of installation procedures, and
describes some special points about installation of individual units.
Item Comments
1.3 Copier
(B234/B235/B236/D101/D102/D103)
• First, install the copier (section 1.3.2).
1.4 A3/11"x17" Tray Unit (B331-11)
1.5 LCIT RT5000 (B832)
1.6 LCIT RT5010 (B834)
The CIS of the image position sensor unit in the
LCT must be calibrated at installation for both LCT
units, B832 and B834 (procedure: 1-49). If you
install the bypass tray, you must install it on the
LCT before you dock the LCT with the machine.
1.7 Multi Bypass Tray (B833) The bypass tray can be installed on either the B832
(1-64, 1-68) or B834 (1-66, 1-68).
1.8 Cover Interposer Tray CI5000 (B835) The next peripheral device must be installed before
completing the installation of the cover interposer
tray (1-76)
1.9 Z-Folding Unit ZF4000 (B660)
• Before installing the Z-folding unit with the
B236/D103(135 cpm) a gear must be replaced so
the unit can keep pace with the higher speed of
the B236/D103 (1-79)
• The breaker switch of the Z-folding unit must be
tested before the unit is docked (1-83)
1.10 Booklet Finisher BK5000 (B836) The booklet finisher has no corner stapler. Corner
stapling is done by the B830.
1.11 Finisher SR5000 (B830)
1.12 Punch Unit PU5000 (B831)
The punch unit is installed in the B830 only.
1.13 Skew And Side-To-Side Adjustment Due to the length of the paper path, if more than
two peripheral devices are installed, the system
must be tested and adjusted after installation. Do
this procedure after installation of all peripheral
units, or after adding a peripheral unit to the system
after installation. (1-106)
1.14 Key Card Counter MK1, MK4 This installation can be done at any time.
1.15 MFP Controller Options
• Only one slot is available for applications. If more
than one application is to be installed, all the
applications must be merged onto 1 SD card. If
the PS3 option will be installed, the applications
must be copied onto the PS3 SD card. (1-124)
• Once an SD card is copied, it cannot be used in
another machine. Copied SD cards serve as
proof of purchase by the customer; therefore,
copied SD cards must be stored on site inside the
copier. (1-127)
1.3 Copier
(B234/B235/B236/D101/D102/D103)
• Then, complete the installation (section 1.3.3).
NOTE: Please refer to the Perfect Binder D391 and Ring Binder B392 manuals
for the installation procedures for these peripheral units.
