5.10.4 UPDATING THE LCDC FOR THE OPERATION PANEL
Follow this procedure to update the LCDC (LCD Control Board).
1. Turn the copier main switch off.
2. Insert the SD card into service slot C3.
3. Switch the copier main switch on.
4. After about 10 seconds the initial screen opens in English.
5. Touch “OpePanel”.
6. Touch “UpDate(#) (or ) to start the update.
After about 9 seconds, the downloading starts and a progress bar appears.
• While the data is downloading, the [Start] key LED flashes RED slowly then
rapidly near completion.
• When the update is finished, the [Start] key flashes GREEN.
• The LCDC update requires about 15 minutes to complete.
7. Switch the copier main power switch off, remove the SD card, then switch the
copier on again.
Exit(0)
ROM: G0000000
ROM: 0.01
ROM: B0705254
ROM: 2.16:16
ROM: B0705370
ROM: 1.22
NEW: G0000000
NEW: 0.0X
NEW: B0705254
NEW: 2.16:16
NEW: B0705370
NEW: 2.00
Printer (1)
Engine (2)
OpePanel.DOM (3)
PCcard -> ROM Page01
UpDate(#)Verify(./*)
B234S913.WMF
To Next Page
