OUTPUT CHECK
B234/B235/B236/D101/D102/D103 5-182 SM
5.5.4 BOOKLET FINISHER OUTPUT CHECK: SP6207
No. Description
001 OFF (Stop)
002 Finisher Engrance Motor
003 Lower Transport Motor
004 Upper Tray Exit Motor
005 Positioning Roiller Motor
006 Jogger Fence Motor
007 Feed-Out Belt Motor
008 Stack Junction Gate Motor
009 Fold Unit Bottom Fence Lift Motor
010 Clamp Roller Retraction Motor
011 Fold Plate Motor
012 Fold Roller Motor
013 Stapling Tray Junction Gate Solenoid
1
014 Stapling Edge Pressure Plate
Solenoid
015 Positioning Roller Solenoide
016 Booklet Pressure Roller Solenoid
017 Booklet Stapler Motor - Front
018 Booklet Stapler Motor - Rear
5.5.5 COVER INTERPOSER (B835) OUTPUT CHECK: SP6401
No. Description
001 OFF (Stop)
002 1st Pick-up Motor
003 2nd Pick-up Motor
004 1st Paper Feed Motor
005 2nd Paper Feed Motor
006 1st Transport Motor
007 2nd Transport Motor
008 Vertical Transport Motor
