LCIT RT5000 (B832)
SM 1-45 B234/B235/B236/D101/D102/D103
Installation
1.5.2 INSTALLATION
CAUTION
Unplug the power cord before starting the following procedure.
1. Remove the visible tape and other items [A] from the covers and left side of the
LCT.
2. Open the LCT door and remove the shipping retainers and tape [B] holding the
levers.
B832I103.WMF
B832I102.WMF
[A]
[B]
