SCANNING
SM 6-37 B234/B235/B236/D101/D102/D103
Detailed
Descriptions
North America
Original APS 3 APS 2 APS 1 SP4301
Display
Name Size L2 L1 W1 W2 W3
DLT SEF 11 x 17 in. Yes Yes Yes Yes Yes 0001 1111
LG SEF 8½ x 14 in. Yes Yes Yes — — 0001 1100
LT SEF 8½ x 11 in. — Yes Yes — — 0000 1100
LT LEF 11 x 8½ x in. — — Yes Yes Yes 0000 0111
HLT SEF 5½ x 8½ — — — — —
O
HLT LEF 8½ x 5½ Yes — — — — 0001 0000
Yes: Detected
—: Not detected
O: Default: Size not detected. However, SP4303 can be set to recognize HLT SEF.
Europe, Oceania, Asia
Original APS 3 APS 2 APS 1 SP4301
Display
Name Size L2 L1 W1 W2 W3
A3 SEF 297 x 420 mm Yes Yes Yes Yes Yes 0001 1111
B4 SEF 257 x 364 mm Yes Yes Yes Yes — 0001 1110
A4 SEF 219 x 297 mm — Yes Yes — — 0000 1100
A4 LEF 297 x 210 mm — — Yes Yes Yes 0000 0111
B5 SEF 182 x 257 mm — Yes — — — 0000 1000
B5 LEF 257 x 182 mm — — Yes Yes — 0000 0110
A5 SEF 148 x 210 mm — — — — —
O
Foolscap SEF
8½ x 13 in. Yes Yes Yes — —
0001 1100*
1
Folio SEF 8¼ x 13 in. Yes Yes Yes — — 0001 1100*
1
F SEF 8 x 13 in. Yes Yes Yes — — 0001 1100*
1
Yes: Detected
—: Not detected
O: Default: Size not detected. However, SP4303 can be set to recognize A5 SEF.
*
1
: With SP 5126, you can select 1 from 3 paper sizes of very similar dimensions. The default is
8½ x" 13", and the other choices are 8¼" x 13", 8" x 13".
Important
• Occasionally, the APS sensors cannot detect the original size accurately if there
is a large amount of black coverage in the original.
• In such cases, the detection of the innermost APS width sensor is ignored and
the detection of the outermost is used to detect the original size.
• When this occurs, the APS readings appear with double underlines when
displayed on the operation panel display with SP4301.
• APS can detect the only the paper sizes in the table above.
