PAPER FEED
3-96
3.10.5 REAR FENCE RETURN SENSOR
1. Turn off the main switch.
2. Pull out the left tandem tray.
3. Rear bottom plate [A] ( x 1).
4. Rear fence return sensor [B] ( x 1).
B234R987.WMF
[B]
[A]
