Motors
SM 3-181
B234/B235/B236/D101/D1
02/D103
Replac
ement
Adjustment
3.16.3 FUSING
MOTOR
•
Open the PSU box (
3.3.8)
•
Open the controller box (
3.3.7)
•
Remove the rear cover (
3.3.6)
1.
Relay board [A] (
x2,
x3,
=
x1)
2.
Timing belt [B] (Loosen
x1, Spring x1)
3.
Fusing motor unit [C] (
x4,
x2)
B234R965.W
MF
[A]
[B]
[C]
404
406
