LCIT RT5000 (B832)
B234/B235/B236/D101/D102/D103 1-46 SM
3. Remove the covers [A] from the right upper side.
4. Remove the covers [B] from the right lower side.
5. Install the pins with the grooved rings [C] on the right upper cover.
6. Install the other pins [D] on the right lower cover.
B832I104.WMF
B832I105.WMF
[B]
[A]
[C]
[D]
