MAIN SERVICE PROGRAM MODE TABLES
B234/B235/B236/D101/D102/D103 5-160 SM
3730
Clear PM Counts
Super User Only
User SP
Use these SP codes to clear the PM count of each TCRU unit after it is replaced.
These SP codes clear the PM counts for the TCRU units only. The PM count must
be set to "0" for each replacement unit so the machine can maintain an accurate
record for its service lift. The TCRU units are the units designated for removal and
replacement at the work site by trained users.
001 Development Unit Clears PM count for a new development unit
002 PCU Clears PM count for a new PCU unit
003 Drum Cleaning Unit Clears PM count for a new drum cleaning unit on the left side
of the drum
004 Charge Corona
Unit
Clears PM count for a new charge unit. The charge unit is
above the drum and to the right of the pre-charge unit. The
charge unit is larger than the pre-charge unit.
005 Pre-Charge Unit Clears PM count for a new pre-transfer unit. The Pre-charge
unit is above the drum and to the left of the charge unit. The
pre-charge unit is smaller than the charge unit.
006 Fusing Unit Clears PM count for a new fusing unit only. The fusing unit
includes the fusing cleaning unit so you must also reset the
PM count for the fusing cleaning unit with SP3730 007.
007 Fusing Cleaning
Web Unit
The web roller and web take-up roller comprise the fusing
cleaning unit. You must do this SP 1) after replacing only the
fusing cleaning unit and 2) after replacing the fusing unit.
3740
Select Test Pattern
Super User Only
User SP
In the image adjustment mode, the machine prints the Trim Pattern when the [Start]
key is pressed. The trim pattern prints a very large rectangle with a narrow margin
between each side of the rectangle and each edge of the paper. The trim pattern is
used to measure the margins and determine whether the side-to-side registration and
other adjustments are set correctly.
[0 to 1/0/1 step]
0: Copy Image (normal operation)
1: Trim Pattern (prints trim pattern)
001 Trim Pattern []
To do a trim pattern:
1. Do this SP and select "1".
2. Touch [Copy Screen] on the display to open the normal copier screen.
3. Select the paper size and color then press the [Start] key to print the trim pattern.
4. After the trim pattern prints, touch [SP Screen].
5. Check the margins of the trim pattern and do the required adjustments.
6. Repeat Steps 2 to 3 to print more patterns to check the effect of the adjustments.
7. After completing all adjustments, do SP3740 again and select "0" to reset the
machine for normal operation.
