PCI Bus Host Bridge
Élan™SC520 Microcontroller User’s Manual 9-7
It is up to the system designer to choose the accuracy of the crystal used with the ÉlanSC520
microcontroller. The 33.000-MHz frequency provides a better guard band than the 33.333-
MHz crystal. In practice, most PCI devices tolerate both frequencies, but it is important to
be aware of the impact of choosing the crystal on this potential violation of the PCI bus
specifications. The PCI bus specification requires that the minimum clock period be 30 ns.
9.4 REGISTERS
The PCI host bridge configuration registers specific to the ÉlanSC520 microcontroller are
memory-mapped in ÉlanSC520 microcontroller configuration space. These registers are
listed in Table 9-1. Table 9-2 lists the direct-mapped registers used to configure the PCI
bus host bridge. The standard PCI configuration space header registers supported on the
ÉlanSC520 microcontroller are shown in Table 9-3 as PCI indexed registers.
Table 9-1 PCI Host Bridge Registers—Memory-Mapped
Register Mnemonic
MMCR
Offset
Address Function
Host Bridge Control HBCTL 60h PCI reset, target FIFO purge enable, automatic
delayed transaction enable, and master write
posting enable
Host Bridge Target Interrupt
Control
HBTGTIRQCTL 62h Target interrupt or NMI select and interrupt
enables: delayed transaction time-out, address
parity, and data parity
Host Bridge Target Interrupt
Status
HBTGTIRQSTA 64h Target interrupt status: delayed transaction time-
out, address parity, data parity; target interrupt
identification
Host Bridge Master Interrupt
Control
HBMSTIRQCTL 66h Master interrupt or NMI select and interrupt
enables: retry time-out, target abort, master
abort, system error, received parity error,
detected parity error
Host Bridge Master Interrupt
Status
HBMSTIRQSTA 68h Master interrupt status: retry time-out, target
abort, master abort, system error, received
parity error, detected parity error; master
command interrupt identification
Host Bridge Master Interrupt
Address
MSTINTADD 6Ch Master address interrupt identification
Interrupt Pin Polarity INTPINPOL D10h Polarity of external interrupt sources (INTA
–
INTD
and GPIRQ10–GPIRQ0)
PCI Host Bridge Interrupt
Mapping
PCIHOSTMAP D14h System arbiter and PCI Host Bridge interrupt
mapping to any of 22 available interrupt
channels or NMI, PCI NMI enable control
PCI Interrupt A Mapping PCIINTAMAP D30h PCI INTA
mapping
PCI Interrupt B Mapping PCIINTBMAP D31h PCI INTB
mapping
PCI Interrupt C Mapping PCIINTCMAP D32h PCI INTC
mapping
PCI Interrupt D Mapping PCIINTDMAP D33h PCI INTD
mapping
