SDRAM Controller
10-14 Élan™SC520 Microcontroller User’s Manual
9-bit 16 Mbit 2 4M x 4 2M x 4 x 2-banks 8 12:9 13-bit 16 Mbytes
2M x 8 1M x 8 x 2-banks 4 11:9 12-bit 8 Mbytes
4 4M x 4 1M x 4 x 4-banks 8 11:9 13-bit 16 Mbytes
64 Mbit 2 16M x 4 8M x 4 x 2-banks 8 14:9 15-bit 64 Mbytes
8M x 8 4M x 8 x 2-banks 4 13:9 14-bit 32 Mbytes
4M x 16 2M x 16 x 2-banks 2 12:9 13-bit 16 Mbytes
2M x 32 1M x 32 x 2-banks 1 11:9 12-bit 8 Mbytes
4 16M x 4 4M x 4 x 4-banks 8 13:9 15-bit 64 Mbytes
8M x 8 2M x 8 x 4-banks 4 12:9 14-bit 32 Mbytes
4M x 16 1M x 16 x 4-banks 2 11:9 13-bit 16 Mbytes
128 Mbit 2 16M x 8 8M x 8 x 2-banks 4 14:9 15-bit 64 Mbytes
8M x 16 4M x 16 x 2-banks 2 13:9 14-bit 32 Mbytes
4M x 32 2M x 32 x 2-banks 1 12:9 13-bit 16 Mbytes
4 16M x 8 4M x 8 x 4-banks 4 13:9 15-bit 64 Mbytes
8M x 16 2M x 16 x 4-banks 2 12:9 14-bit 32 Mbytes
4M x 32 1M x 32 x 4-banks 1 11:9 13-bit 16 Mbytes
256 Mbit 2 16M x 16 8M x 16 x 2-banks 2 14:9 15-bit 64 Mbytes
8M x 32 4M x 32 x 2-banks 1 13:9 14-bit 32 Mbytes
4 16M x 16 4M x 16 x 4-banks 2 13:9 15-bit 64 Mbytes
8M x 32 2M x 32 x 4-banks 1 12:9 14-bit 32 Mbytes
10-bit 16 Mbit 2 4M x 4 2M x 4 x 2-banks 8 11:10 12-bit 16 Mbytes
64 Mbit 2 16M x 4 8M x 4 x 2-banks 8 13:10 14-bit 64 Mbytes
8M x 8 4M x 8 x 2-banks 4 12:10 13-bit 32 Mbytes
4M x 16 2M x 16 x 2-banks 2 11:10 12-bit 16 Mbytes
4 16M x 4 4M x 4 x 4-banks 8 12:10 14-bit 64 Mbytes
8M x 8 2M x 8 x 4-banks 4 11:10 13-bit 32 Mbytes
128 Mbit 2 32M x 4 16M x 4 x 2-banks 8 14:10 15-bit 128 Mbytes
16M x 8 8M x 8 x 2-banks 4 13:10 14-bit 64 Mbytes
8M x 16 4M x 16 x 2-banks 2 12:10 13-bit 32 Mbytes
4M x 32 2M x 32 x 2-banks 1 11:10 12-bit 16 Mbytes
4 32M x 4 8M x 4 x 4-banks 8 13:10 15-bit 128 Mbytes
16M x 8 4M x 8 x 4-banks 4 12:10 14-bit 64 Mbytes
8M x 16 2M x 16 x 4-banks 2 11:10 13-bit 32 Mbytes
256 Mbit 2 32M x 8 16M x 8 x 2-banks 4 14:10 15-bit 128 Mbytes
16M x 16 8M x 16 x 2-banks 2 13:10 14-bit 64 Mbytes
8M x 32 4M x 32 x 2-banks 1 12:10 13-bit 32 Mbytes
4 32M x 8 8M x 8 x 4-banks 4 13:10 15-bit 128 Mbytes
16M x 16 4M x 16 x 4-banks 2 12:10 14-bit 64 Mbytes
8M x 32 2M x 32 x 4-banks 1 11:10 13-bit 32 Mbytes
Table 10-8 SDRAM Devices Supported with Column Boundary Specification (Continued)
Column
Width Density Banks Organization Device Architecture
Device
Count
per Bank
Dimension
Row: Col
MA/BA
Width
Bank
(32-Bit)
