Boundary Scan Test Interface
Élan™SC520 Microcontroller User’s Manual 25-7
SWEB Output 111
SWEA
Output 112
Control 113
SDQM3 Output 114
SDQM2 Output 115
SDQM1 Output 116
SDQM0 Output 117
Control 118
BOOTCS
Output 119
Control 120
ROMRD
Output 121
Control 122
FLASHWR
Output 123
Control 124
ROMBUFOE
Output 125
Control 126
ROMCS1
Output 127
Control 128
ROMCS2
Output 129
Control 130
AD31 Bidirectional 131, 132
AD30 Bidirectional 133, 134
AD29 Bidirectional 135, 136
AD28 Bidirectional 137, 138
AD27 Bidirectional 139, 140
AD26 Bidirectional 141, 142
AD25 Bidirectional 143, 144
AD24 Bidirectional 145, 146
AD23 Bidirectional 147, 148
AD22 Bidirectional 149, 150
AD21 Bidirectional 151, 152
AD20 Bidirectional 153, 154
AD19 Bidirectional 155, 156
AD18 Bidirectional 157, 158
AD17 Bidirectional 159, 160
AD16 Bidirectional 161, 162
AD15 Bidirectional 163, 164
AD14 Bidirectional 165, 166
AD13 Bidirectional 167, 168
AD12 Bidirectional 169, 170
AD11 Bidirectional 171, 172
AD10 Bidirectional 173, 174
Table 25-3 Main Data Scan Path (Continued)
Pad Name Scan Type Boundary Scan Order
