ACCESS CONTROL LIST COMMANDS
The Access Control List commands in the Command Line Interface (CLI) are listed (along with the
appropriate parameters) in the following table.
Command
Parameter
create access_profile
[ ethernet {vlan | source_mac <macmask> | destination_mac <macmask> |
802.1p | ethernet_type} | ip { source_ip_mask <netmask> | destination_ip_mask
<netmask> | dscp | [ icmp { type | code } | igmp { type } | tcp { src_port_mask
<hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff> | flag_mask} | udp
{ src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff> } |
protocol_id_mask <0x0-0xff> ]} | packet_content_mask {offset1 [ l2 | l3 | l4 ]
<value (0-31)> <hex (0x0-0xffff)> | offset2 [ l2 | l3 | l4 ] <value (0-31)> <hex (0x0-
0xffff)>| offset3 [ l2 | l3 | l4 ] <value (0-31)> <hex (0x0-0xffff)>| offset4 [ l2 | l3 | l4 ]
<value (0-31)> <hex (0x0-0xffff)>} | ipv6 { class | source_ipv6_mask <ipv6mask>
| destination_ipv6_mask <ipv6mask> | [tcp { src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff>} | udp { src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff>} | icmp { type | code } ]} profile_id <value 1-10> ]
config access_profile
profile_id <value (1-10)> [add access_id [auto_assign | <value 1-128>] [ ethernet
{vlan <vlanid (1-4094)> | source_mac <macaddr> | destination_mac <macaddr> |
802.1p <value (0-7)> | ethernet_type <hex (0x0-0xffff)> } | ip {source_ip <ipaddr>
| destination_ip <ipaddr> | dscp <value (0-63)> | icmp {type <value (0-255)> code
<value (0-255)>} | igmp {type <value (0-255)>} | tcp {src_port <value (0-65535)> |
dst_port <value (0-65535)> | urg | ack | psh | rst | syn | fin} | udp {src_port <value
(0-65535)> | dst_port <value (0-65535)>} | protocol_id <value(0-255)>]} |
packet_content [offset1 <hex (0x0-0xffffffff)> | offset2 <hex (0x0-0xffffffff)> |
offset3 <hex (0x0-0xffffffff)> | offset4 <hex (0x0-0xffffffff)>] | ipv6 [class <value 0-
255> | source_ipv6 <ipv6addr> | destination_ipv6 <ipv6addr> | tcp [src_port <
value 0-65535> | dst_port < value 0-65535>] | udp [src_port < value 0-65535> |
dst_port < value 0-65535>] | icmp [type<value 0-255> | code <value 0-255>] ]
[port [<portlist> | all] [permit {replace_priority_with <value (0-7)> |
replace_dscp_with <value (0-63)> | rx_rate {no_limit | <value (64-1024000)>}} |
mirror | deny]] | delete access_id <value (1-128)>]
delete access_profile
profile_id <value 1-10>
show access_profile
{profile_id <value 1-10>}
create
cpu_access_profile
[ ethernet {vlan | source_mac <macmask> | destination_mac <macmask> |
802.1p | ethernet_type} | ip {source_ip_mask <netmask> | destination_ip_mask
<netmask> | dscp | [ icmp {type | code} | igmp {type} | tcp {src_port_mask <hex
(0x0-0xffff)> | dst_port_mask <hex (0x0-0xffff)> | flag_mask} | udp
{src_port_mask <hex (0x0-0xffff)> | dst_port_mask <hex (0x0-0xffff)>} |
protocol_id_mask <hex (0x0-0xff)>]} | ipv6 {class | source_ipv6_mask
<ipv6mask> | destination_ipv6_mask <ipv6mask>} ] profile_id <value 1-3>
config
cpu_access_profile
[profile_id <value (1-3)] [add access_id [ auto_assign | <value (1-5)>]] [ ethernet
{vlan <vlanid (1-4094)> | source_mac <macaddr> | destination_mac <macaddr> |
802.1p <value (0-7)> | ethernet_type <hex (0x0-0xffff)>} | ip {source_ip <ipaddr> |
destination_ip <ipaddr> | dscp <value (0-63)> | [icmp {type <value (0-255)> code
<value (0-255)> } | igmp {type <value (0-255)>} | tcp {src_port <value (0-65535)>
| dst_port <value (0-65535)> | urg | ack | psh | rst | syn | fin} | udp {src_port
<value (0-65535)> | dst_port <value (0-65535)> | protocol_id <value(0-255)>] |
ipv6 {class | source_ipv6 <ipv6addr> | destination_ipv6 <ipv6addr>} [port
