Cardiacoutput

10.Swan-Ganzthermodilutioncatheter

11.Thermistorconnector

12.Balloon

13.Ballooninationvalve

C.O.equipmenttopatientconnectionwithabathprobe

1.ModulewithC.O.measurementcapability

2.Cardiacoutputcable

3.Thermistorconnector

4.Injectatetemperaturebathprobe

5.Injectateuid

6.Injectatesyringe

7.Proximalinjectateport

8.PAdistalport

9.Ballooninationvalve

10.Swan-Ganzthermodilutioncatheter

11.Balloon

C.O.modulekey

ThereisoneC.O.modulekeyontheE-COPandE-COPSvmodules:

StartC.O.

Startsandstopsthecardiacoutputmeasurement.

PreparingtheC.O.measurement

1.ConnecttheC.O.cabletotheacquisitionmodule,thermistor,andinjectate

temperatureport.

2062971-001CARESCAPEModularMonitors263
