Systemintroduction
environmentitmustalwaysbepoweredfromanadditionaltransformerproviding
atleastbasicisolation.
7.PRN50-Mrecorder:Thisdevicemaybeconnecteddirectlytothemonitoror
overthenetworktoaremotemonitororcentralstation.Therecordercanprint
waveforms,alarmwaveforms,andnumerictrends.
8.UnityNetworkInterfaceDevice(ID):Usedwiththemonitortocommunicatewith
othermanufacturers’peripheralbedsidedevices,suchasventilatorsandgas
deliverysystems,tocentralizepatientdataononedevice.
9.Mouse.
10.RemoteAlarmBox(nursecallsystem):Usedtonotifyaremotelocationofpatient
alarmsandsystemalarms.
11.Remotecontrolandkeypad:Usedtoprovideallpatientmonitorcontrolsona
portablecomponentwithaTrimKnobcontrol.
12.Barcodereader:UsedtoscanaTechnicianIDandPatientInformationNumber
frombarcodeswhenadmittingpatients.
13.Keyboard:Allowsdataentrywithoutusingtheon-screenkeyboardora
touchscreendisplay.
B850processingunitfrontview
FourM-portconnectorsarelocatedontheprocessingunit.TheM-portsareusedto
connectperipheraldevicestothemonitor.
1.Powerindicator:Illuminatesgreenwhenthepoweristurnedon.
2.M-ports:Connecttheremotecontrol,PRN50-Mrecorder,remotealarmbox
(remotenursecall),oraUnityNetworkInterfaceDevice(ID)tothemonitor.
B850processingunitbackview
1.Poweron/offswitch.
2.Powerinletconnector.
3.FourUSBports:Forconnectingthetouchscreendisplay,remotecontrol,keyboard,
mouse,andbarcodereader.
56CARESCAPEModularMonitors2062971-001
