Monitoringbasics

RemovingotherE-modulesthanPSMfromaframe

1.Pressthereleaselatchatthebottomofthemodule.

2.Whilepressingthereleaselatch,graspthemodulermlyandpullout.

ConnectingTRAMmodulestoaTram-Rachousing

NOTE

ATRAMmodulemustalwaysoccupythetoppositioninthe

Tram-Rachousing.Othermodulesareinstalledbelowit.

1.FacetheTram-Rachousingandguidethebackofthemoduleintotheappropriate

position.

2.Gentlypushthemoduleintothehousing.Youwillhearaclickwhenthemoduleis

fullyinserted.

RemovingTRAMmodulesfromaTram-Rachousing

1.PushthemoduleintotheTram-Rachousing.Thisreleasesthemoduleandmakes

iteasiertoremove.

2.Pressandholdthereleaseleversfoundoneachsideofthefrontofthemodule.

3.Pullthemoduleoutabout15cm(6in).

4.Graspthemodulermlywithbothhandsandremoveit.Donottrytoholdthe

modulebythereleaselevers.

2062971-001CARESCAPEModularMonitors95
