GE CARESCAPE - BIS measurement setup; BIS equipment to patient connection; BIS module keys; Preparing the patient for BIS measurement

Bispectralindex
BISmeasurementsetup
BISequipmenttopatientconnection
1.ModulewithBISmeasurementcapability,E-BIS
2.DigitalSignalProcessingUnit,BISx
3.PatientInterfaceCable,PICPlus
4.BISsensor
BISmodulekeys
Therearetwokeysonthemodule:
OpensorclosestheBISmenuonthescreen.
Startsthemanualsensorcheck.
PreparingthepatientforBISmeasurement
1.Connectthedigitalsignalprocessingunit(BISx)cabletothemodule.
2.ConnectthepatientinterfacecabletotheBISx.
3.SecuretheBISxtoaconvenientlocation,preferablyclosetothepatient’shead.
4.Cleantheapplicationsitewithalcoholandletdry.
5.PlacetheBISsensoronthepatient;seesensorpackageforinstructions.
6.Connectthesensortothepatientinterfacecable.
7.Observetheresultsoftheautomaticsensorcheckintheparameterwindow.
8.Themeasurementstartsautomaticallyafterthesensorhaspassedthecheck.
CheckingtheBISmeasurement
1.Checkthatthesensor/electrodepassesthesensor/electrodecheckwhenyou
arestartingtomonitoranewpatient.
