PatientSpirometry

NOTE

Notmeasuredwithspontaneousbreaths.

●Airwayresistance(Raw):calculatedfromanequationdescribingthekineticsofgas

owbetweenthelungsandaowsensor.

NOTE

Notmeasuredwithspontaneousbreaths.

●Realtimewaveform(Flow)

●Ratiooftheinspiratoryandexpiratorytime(I:E)

●Pressure-volumeloop(Paw-Vol.loop)

●Flow-volumeloop(Flow-Vol.loop)

Airwaypressures

Airwaypressurewaveformontherightandpressure-volumeloopontheleft:

●x=Paw

●y=Vol

1.Ppeak

2.Pplat

3.Pmean

4.PEEPe

5.PEEPtot

6.(PEEPi=PEEPtot—PEEPe)

NOTE

PEEPeandPEEPinotavailableinORandPACUsoftware

packages.

PEEPtot

NOTE

ThefollowingloopillustrateshowPEEPtot(=PEEPe+PEEPi)isdisplayed.

330CARESCAPEModularMonitors2062971-001
