Systemintroduction

Thefollowingsymbolsappearononeormoreofthedevices.

Signal/powerinput.

Signal/poweroutput.

Signal/powerinput/output(combined).

ON.Powerconnectiontothemains.

Powersupplyconnector.

Powerswitch.

Displaybrightnesscontrols.

Displayspeakervolumecontrols.

USBconnectors.

Ethernetconnectors.

Serialinterface.

2062971-001CARESCAPEModularMonitors83
