Systemintroduction

Thefollowingsymbolsappearononeormoreofthedevices.

Manufacturernameandaddress.

Batchorlotnumber.

Abbreviationforlabelpartnumber.

Catalogueororderablepartnumber.

Deviceserialnumber.

Atmosphericpressurelimitations.

Temperaturelimitations.

Humiditylimitations.

Keepdry.Protectfromrain.

Fragile.Handlewithcare.

Thiswayup.

Thissymbolindicatesthatthewasteofelectricalandelectronic

equipmentmustnotbedisposedasunsortedmunicipalwaste

andmustbecollectedseparately.Pleasecontactanauthorized

representativeofthemanufacturerforinformationconcerning

thedecommissioningofyourequipment.

86CARESCAPEModularMonitors2062971-001
