Systemintroduction
Thefollowingsymbolsappearinthesoftwareuserinterface.
BISandEntropysensorimpedancecheckindicator(gray).
Displaysforeachsensorastheimpedancecheckisinprogress.
BISandEntropysensorimpedancecheckerrorindicator(red).
Indicatesthespeciedsensorfailedtheimpedancecheck.
BISandEntropysensorimpedancecheckpassedindicator.
Indicatesthespeciedsensorpassedtheimpedancecheck.
CompletedNIBPvolumeicon.Adjustthevolumeofthetonethat
soundswhenanNIBPmeasurementresultisavailable.
ManualNIBPicon.StartamanualNIBPmeasurement.
NellcorOxiMaxSatSecondsindicator.Indicatestheamountof
timetheSpO
2
saturationisoutsidethelimitsbeforealarmsare
generated.
SpO
2
signalstrengthindicator.Indicatesthesignalstrength,with
threeasterisksindicatingthestrongestsignal.
NMTStimulusbeepvolumeicon.Adjustthevolumeofthetone
thatsoundswhenastimuluspulseisgenerated.
Progressbar.Indicatestheamountoftimeremaininguntilthe
nextautomaticmeasurement.
