Touch Setup
● Initialize
From the Main Menu, press Initial Setting, and then Initialize to display the initialization menu screen.
You can use this screen to set the following items. Press the button for each item to set it.
■ Alarm Log
Clears all the Alarm Log data.
From the Main Menu, press Initial Setting, Initialize, and then Alarm Log.
Press Yes to clear the Alarm Log data.
■ Data Log
Clears all the Data Log data.
From the Main Menu, press Initial Setting, Initialize, and then Data Log.
Press Yes to clear the Data Log data.
■ Op. Log (Operation Log)
Clears all the Operation Log data.
From the Main Menu, press Initial Setting, Initialize, and then Op. Log.
Press Yes to clear the Operation Log data.
■ Touch PnlAdj (Touch Panel Adjust)
Adjusts the analog touch panel.
From the Main Menu, press Initial Setting, Initialize, and then Touch PnlAdj.
Press Yes and adjust according to the instructions on the screen.
●
Comm. Driver (Communication Driver)
From the Main Menu, press Initial Setting, and then Comm. Driver to display the communication driver menu
screen.
To specify settings, press the button to select a choice. Comm. Driver setting items vary based on the currently
connected hardware. For details about settings, refer to the "External Device Setup Manual".
If No External Devices are selected from the Communication Driver, some settings cannot be modified.
●
O/I Link
From the Main Menu, press Initial Setting, and then O/I Link to display the O/I link menu screen.
This screen displays information on the O/I Link.
(Various settings can be made by pressing O/I Link Set 1 and O/I Link Set 2.)
• To return to the initial settings screen, press Init Set at the top of the screen.
• To return to the initialization menu screen from any of the settings screens below, press Init at the top of
the screen.
Press the center of displayed on the screen, in the following order: lower-left corner, lower-right
corner, upper-left corner, upper-right corner of the Touch screen. The position of the analog touch
panel is properly adjusted and set.
Pressthecenterof
thesymbol.
To return to the initial settings screen, press Init Set at the top of the screen.
• To return to the initial settings screen, press Init Set at the top of the screen.
• For details about settings, refer to the "External Device Setup Manual".
