3 Settings
28-8 SmartAXIS Touch User's Manual
● Comm. I/F (Communication Interface)
From the Main Menu, press Initial Setting, and then Comm. I/F to display the communication interface settings
menu screen.
You can use this screen to set the items below. Press the button for each item to set.
■ RS232C
Allows the setting of communication parameters for the Serial Interface Port (RS232C).
From the Main Menu, press Initial Setting, Comm. I/F, and then RS232C.
■ RS422/485
Allows the setting of communication parameters for the Serial Interface Port (RS422/485).
From the Main Menu, press Initial Setting, Comm. I/F, and then RS422/485.
■ IP Address
Allows the setting of the IP address and subnet mask.
From the Main Menu, press Initial Setting, Comm. I/F, and then IP Address.
Press <-- or --> to select an item, and then use the Keypad to enter the IP address and subnet mask values.
Press ENT to apply the entered values.
■ Default Gateway
Specify the default gateway.
From the Main Menu, press Initial Setting, Comm. I/F, and then Default Gateway.
Press <-- or --> to select an item, and then use the Keypad to enter the default gateway value. Press ENT to apply
the entered value.
■ Misc Setting (Miscellaneous Setting)
Specify whether to allow or prohibit Maintenance Communication via TCP/IP (refer to Chapter 23 “Using the online
function for Ethernet communication” on page 23-7).
From the Main Menu, press Initial Setting, Comm. I/F, and then Misc Setting.
Each press of CHG changes the property of the selected item. Repeat this procedure until the desired properties are
displayed.
Press ENT to apply the entered value.
■ Ext. IP Address (External Device IP Address)
Changes the IP addresses for the external device.
From the Main Menu, press Initial Setting, Comm. I/F, and then Ext. IP Address.
Procedure
1 Press <-- or --> to select the station number, and then enter the station number value with the numeric keypad.
2 Press ENT to confirm the entered value. The IP address for the selected station number is displayed.
3 Press <-- or --> to select the item, and then enter the IP address with the numeric keypad.
4 Press ENT to confirm the entered value.
5 Press SAVE to save the settings.
• To return to the initial settings screen, press Init Set at the top of the screen.
•Press Comm. I/F at the top of the screen to return to the communication interface settings menu
screen.
The setting is not updated if you display another screen before applying the setting.
The setting is not updated if you display another screen before applying the setting.
The setting is not updated if you display another screen before applying the setting.
If you switch to another screen or change the station number before pressing SAVE, the settings are not
saved.
