1 Numerical Input
9-6 SmartAXIS Touch User’s Manual
Example: When the Always Entry Mode check box is cleared
■ Focus is moved by ENT button
*1
When multiple Numerical Inputs are configured on the screen, select this check box to continue entering values on
each of the Numerical Inputs.
Each time ENT is pressed, the focus moves between the Numerical Inputs according to Focus Order. On the View
tab, in the Screens group, click Focus Order, and then click the Numerical Inputs in the order to move the focus.
Example: When Numerical Input A and B are configured and the Focus is moved by ENT button check box for
Numerical Input A is selected and the Focus is moved by ENT button check box for Numerical Input B is
cleared
*1 Advanced mode only
