4 Message Display
9
Data Displays
● Options Tab
The Options tab is displayed in Advanced mode.
■ Change Color by Device
Switches the message or plate color.
Enable: Select this check box to switch the color of the message or plate depending on
the value of device.
Device: Specifies the word device that stores the color data for the message or plate.
Click to display the Device Address Settings dialog box. For the device
address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-62.
Color data assignments that are stored to devices are given below.
This uses address+1 to specify the text color and plate color when the Enable
check box has been selected.
For color data, refer to Appendix “1 Color Number Correspondence Table” on
page A-1.
D0=
Lower byteUpper byte
0x00
Lower byteUpper byte
0xF7
D0=
Lower byteUpper byte
0x900xF7
D0
0x00
0xF7
Lower byteUpper byte
D0
0x90
0xF7
FT SERIES
FT SERIES
TouchExternal device
Text colorPlate color
Text colorPlate color
Device
bit bit
15 8
bit
7
bit
0
Upper byte
Plate color
Address
Device
Text color
Plate color when blinking
Address+1
Text color when blinking
Lower byte
