SmartAXIS Touch User’s Manual 10-43
3 Pie Chart
10
Charts
■ Pattern
Selects the chart pattern.
Click this button to display the Pattern Palette. Select a pattern from the Pattern Palette.
■ Set
Registers the chart settings to the list. If you select a Ch number that is already registered, that number is overwritten
with the new settings.
Select a Ch number on the list, and then click this button to register the Reference Device, Foreground Color,
Background Color, and Pattern settings.
■ Insert
Inserts the chart settings in the position selected on the list.
Select a Ch number on the list, and then click this button to insert the Reference Device, Foreground Color,
Background Color, and Pattern settings. The settings at the insertion point shift down one line. Settings cannot be
inserted if all Ch numbers are configured.
■ Remove
Deletes the registered settings from the list.
Select a Ch number, and then click this button to delete the selected settings from the list.
